Model #

PT-6KS

PT-6KL

PT-10KS

      PT-10KL

Capacity

6KVA/6000W

10KVA/10000W

Front panel

Rear panel

Display

LCD

INPUT

Input voltage range

110~300VAC,110~176VAC,280~300VAC(power limited)

Input frequency range

50/60Hz±6Hz,± 10Hz (setable)

OUTPUT

Output voltage range

208/220/230/240VAC

Output frequency

AC mode: same as AC ,Battery mode:50/60Hz±1%

Wave form

Pure Sinewave

Transfer time

0ms

BATTERY

QTY & capacity of battery

20pcs*12V7Ah

Charging period

4~6 hours recover to 90% capacity

PROTECTION & FUNCTION

PROTECTION

1. Battery low voltage protection
2. Overload protection
3. Short circuit protection

MANAGEMENT

RS232 & USB &

EPO

Optional

PHYSICAL

Unit dimension (mm)

461*200*800

461*200*360

461*200*800

Master box dimension (mm)

605*300*989

Pcs in one master carton

Gross weight (1pc, kg)

Net weight (1pc, kg)

55

12.4

55.25

12.7
